VGM Sand tipping trailer ZK30-2 ALU

arrow_backReturn to transportation

VGM tipper ZK 30-2 alu offers you a maximum load capacity. The triangle suspension ensures optimum stability




ZK 30-2 alu

Tridem heavy transport tipping trailer

10 hole shafts 150 mm

410 x 180

Hydraulic suspension axle suspension TRIDEC HDO

First and third axis forced

Hydraulic double acting support leg

Hydraulic double acting tailgate

Tapered container, therefore better releasing

Plate thickness of the loading bucket 6mm Hardox400

Six wheels hydraulically braked

Width lighting front and rear

Rotatable towing eye

Rear towbar

Hose support on the drawbar

Hydraulic suspension drawbar

Screwed mudguards on the loading platform

Container dimensions

6600 int. x 2300 int. x 1180 int.

Tipping cylinder mounted in gimbal suspension

Track size

1950 mm

  • Hydraulic drawbar suspension
  • Hydraulic towing foot with hand pump
  • Hydraulic towing foot with six-way crane
  • Air brake
  • Air brake combined with hydr.
  • Air brakes + ALR valve
  • Lockable control box
  • 2 work lights on the back
  • Follower plug on the back
  • LED-lighting
  • Reverse zoomer
  • Plastic toolbox
  • Scharmüller K80 towbar
  • Prepare PVG
  • Water barrier screwable ZK-2
  • Sprayed in company color
  • Automatic lubrication system
  • Stairs on aluminum cover shutters
  • ZK30-2 aluminum roof hatches type MK2
  • ZK-2 Top edge rear hatch with asphalt valve
  • Protection on aluminum cover shutters
  • Scoop support at the bottom of the container
  • ZK-2 Dredge Toggle
  • ZK-2 Bumper foldable TÜV-PVG
  • Bumper ZK-2
  • Semi automatic height adjustment
  • PTO pump with quick pocket valve
